Pride Matrix Hubs Splash Black/Silver - 10/10mm - 28H

NON-CONTRACTUAL PHOTO

PRIDE MATRIX HUBS

Pride Matrix hubs represent the top-end of Pride Racing, designed to deliver peak performance and maximum responsiveness on the track.

Engineered for near-instant engagement without compromising weight, the Matrix features an innovative engagement system for almost immediate power transfer, perfect for explosive starts and technical accelerations. The core system uses two rows of 6 pawls, 12 pawls in total, alternating for 216 engagement points with an ultra-reduced angle of 1.67° for nearly instant response on each pedal stroke.

To solve common BMX issues such as brake caliper and spoke interference, the rear hub is optimized for 120mm rotors with improved clearance.

Matrix hubs are a benchmark for riders seeking precision, responsiveness, and reliability without compromise.

NOTE: Lock ring and spacers are provided with the hub

SPECIFICATIONS

• Material: Aluminium 6061-T6
• Front spacing: 100x10mm
• Rear spacing: 110x10mm
• Number of holes: 28
• Driver standard: Shimano
• Engagement type: 216 points / 12 pawls
• Disc mount: ISO6
• Front hub bearing: 6902 (15x28x7mm)
• Rear hub bearing: 18307 (18x30x7mm)
• Weight: 182g (Front) / 349g (Rear)
